In StockAirOzone Ozone Generator
£512.96£569.95Save £56.99
In stock
or buy it now with
Free UK mainland delivery over £90.00, otherwise £6.95. Order by 2pm for same-day dispatch, Monday to Friday. Details
Questions about this product? Ask us or see delivery & returns.
Description
AirOzone ozone generators eliminate any unwanted odours from the air in ventilation systems before it leaves the ducting.
Available in a variety of sizes to suit most needs, the AirOzone ozone generators can be matched to most airflows as it is important not to exceed the airflow limitations of each model.
|
AirOzone 150 |
Diameter: 150mm Ozone Plates:1 Max Air Flow: 600m³/h |
| AirOzone 200 | Diameter: 200mm Ozone Plates: 2 Max Air Flow: 1200m³/h |
| AirOzone 250 | Diameter: 250mm Ozone Plates: 3 Max Air Flow: 1800m³/h |
| AirOzone 315 | Diameter: 315mm Ozone Plates: 5 Max Air Flow: 3000m³/h |
| AirOzone 355 | Diameter: 355mm Ozone Plates: 8 Max Air Flow: 4800m³/h |
Attached inline after the outtake (exhaust) fan, ozone generators need a minimum run of 5m of ducting after them to be effective.
Please note ozone can be hazardous, it must be vented outdoors - never indoors. =
AirOzone ozone generators can be serviced by Global Air Supplies when the plates are no longer running at maximum capacity.
Key facts
| Type | Inline ozone generator for the exhaust ducting |
|---|---|
| AirOzone 150 | 150 mm, 1 ozone plate, up to 600 m³/h |
| AirOzone 200 | 200 mm, 2 plates, up to 1200 m³/h |
| AirOzone 250 | 250 mm, 3 plates, up to 1800 m³/h |
| AirOzone 315 | 315 mm, 5 plates, up to 3000 m³/h |
| AirOzone 355 | 355 mm, 8 plates, up to 4800 m³/h |
| Ducting after it | At least 5 m |
| Servicing | Global Air Supplies service the plates when they stop running at full capacity |
| Brand | AirOzone |
| Sizes | AirOzone 150, AirOzone 200, AirOzone 250, AirOzone 315, AirOzone 355 |
| Category | Carbon Filters and Air Fresheners |
How to use
Choose the model for your duct size, and never one whose maximum airflow is below your fan's. Fit it inline after the extraction fan, with at least 5 m of ducting after it so the ozone has time to work on the air.
Ozone can be hazardous. It must be vented outdoors, never indoors.
Our fan and carbon filter size guide helps you work out your airflow.
Questions
Where does the ozone generator go?
Inline in the exhaust ducting, after the extraction fan, with at least 5 m of ducting after it. The air must vent outdoors.
Is ozone safe?
Ozone can be hazardous, which is why the exhaust must always vent outdoors, never indoors.
Which model do I need?
The one that matches your duct size, without going over its maximum airflow: from 600 m³/h for the AirOzone 150 to 4800 m³/h for the 355.
